Caigang tile insulation composite board production can choose caigang tile insulation composite board continuous production line, the machine picture is as follows:
Caigang tile thermal insulation composite board continuous production line with high degree of automation, easy operation, stable operation and other characteristics, the production of flat surface, interface gap precision and beautiful advantages. It should be able to meet the continuous production of composite sandwich board with polyurethane core material, that is, liquid material is continuously sprayed to the upper and lower panel of pressing molding, and react, foam, solidify and form in double-track foaming molding machine.
Equipment application: the production line is used for continuous production of polyurethane cold storage board, wall board type double-sided rigid insulation board.
Main technical parameters:
Production Line Speed | 2～5m/min |
Cold storage plate metal forming machine | 6m 7 main roller |
Wall panel metal molding machine | 7.5m 9 main roller |
Laminated conveyor length | 24m |
Maximum heating temperature | 70℃ |
Speed of cloth dispenser | 100mm/s |
Adjust the distance back and forth of the cloth dispenser | 500mm |
Length of preheated drying passage | 500mm |
Length of preheated drying passage | 5000mm |
High pressure foam model | LXPU-H2-B30 |
Overall dimension of production line (length × widest part) | ＞120000mm×6000mm |
total power | About 160kw (heating about 65kw) |
Equipment color: | Main color beige white (optional) |
